(1) The use of an inorganic shell structure in the motor effectively reduces its thermal conductivity and improves its heat dissipation capability.
(2) Strong overload capacity, S3 working system can reach 1.5 times 40%, Z18 series motors have a maximum overload capacity of>2.5 times.
Our company has a complete self owned production supply chain, and all raw materials are sourced from well-known international and domestic suppliers (such as Baosteel, Taiyuan Iron and Steel, SKF, NACHI, etc.). Our industrial park has a complete production line from punching and cutting, die-casting, offline, dipping and painting to assembly and testing, which is an important guarantee for motor quality.
(4) The high standard motor factory inspection standard implements full factory inspection of technical indicators such as motor vibration, shaft jump, and end jump, and the standard requirements are higher than those of similar products.
Click on the empty space to go back
![]()
Z18 SERIES SERVO SPINDLE MOTOR—Z18-4015XE10
Rated Power(Kw):30
Rated Torque(N.m):287
Rated Speed(r/min):1000
Max Speed(r/min):4500
- Description
- Product Parameter
